Detailed overview of the CENOS Simulation Platform focusing on frequently discussed topics related to induction heating simulation.
Get an overview of meshing, geometry, and visualizations. You are welcome to join active discussions with the hosts to learn all about the CENOS Simulation Platform.
In this video we talk about CENOS Sliced geometry setup:
- Pros and Cons of Sliced Geometries
- FromCAD approach with a sliced geometry
- Physics setup differences with a Sliced Geometry
Video is split into chapters, but for full understanding of how and when to apply specific sliced boundary conditions, it is recommended to watch the whole video and listen to the comments made as the case setups are happening.
Chapters:
0:00 Introduction about sliced geometries
3:30 Spur gear case: Geometry input
4:37 Spur gear case: FromCAD inputs
8:50 Spur gear case: Physics inputs
14:18 Bearing hardening rotation case: FromCAD inputs
20:04 Bearing hardening rotation case: Physics inputs
24:57 Rectangular bar scanning case: FromCAD inputs
30:10 Rectangular bar scanning case: Physics inputs
33:18 Questions and Comments
